Nova Kool R4509 12-24 Volt 122L Marine Fridge/Freezer Suitable for Boats, Caravans, Motorhomes and RVs (R4500)

Nova Kool R4509 12-24 Volt 122L Marine Fridge/Freezer Suitable for Boats, Caravans, Motorhomes and RVs (R4500)

Nova Kool R4509 - 122 Litre Fridge/Freezer

Single Door with Black Frame (Standard)

106 Litre Fridge with 16 Litre Freezer Compartment

Ask us for a quote - we can ship Australia wide!!

When the compressor is running, the R4509 draws only 4.0 amps @ 12 Volts DC - less than 0.5 amps on the 120VAC option. All Nova Kool Refrigerators and Freezers are equipped with a highly efficient variable speed Danfoss BD series compressor that is designed to run even while you are listed at a 30° angle. Average power use will vary depending on ambient temperature and how often the door is opened etc. but you can expect the R4509 to use less than 38 amp hours per day at 30C ambient temperature.


  • 122 Litres Total
  • Internal Volume106 litres of fridge space with 16 litre freezer box

Cut Out Dimensions:

  • 720 mm (H) X 515 mm (W) x 533 mm (D)
  • This model has a black flange included.


  • Highly efficient variable speed Danfoss BD Series compressor (fan included) that is designed to run well even at very high ambient temperatures and at angles up to 30° off level.
  • Supplied standard with Black door panels.
  • Door swing is right hand as standard but this can be changed prior to shipping or you can change this easily yourself.
  • Positive latch system
  • Storage for tall bottles
  • Reversible door swing
  • Replaceable door panels for a custom finish to your interior
  • Backed with Nova*Kool's Easy 2 Year Warranty Program on all components
  • Environmentally sound 134a refrigerant
  • CFC free urethane foam insulation in cabinet and doors
  • Magnetic door gaskets for positive seal
  • Stainless fasteners & hinges used throughout
  • Maintenance friendly & efficient static condenser
  • Low battery protection to help prevent full discharge of batteries
  • Strongest mounting flanges in the industry - Stainless Steel.
  • Made in Canada
  • All Nova Kool units can add the AC/DC Module as an optional extra if required
  • Compressor Fan - supplied
  • Interior Light - option


  • Standard with Right Hand Hinge Configuration. Left Hand Hinge available on request at no extra charge. The hinge side is user configurable, however, let us know your preference at the time of order and we can have the change made at factory prior to shipping/pick-up.



          Volume 122 Litres (4.3 cu.ft. ) volume
          122 total litres internal volume: 106 litres of fridge space and a 16 litre freezer box at the top

          Cut Out Dimensions 720mm Height
          515mm Width

          533mm Depth (measured from the back face of the mounting flange)

          Overall dimensions (Including flange)
          745mm Height
          536mm Width

          612mm Depth (including door and latch handle)
