Nova Kool R3802DC 12-24 Volt 100 Litre Marine Fridge Only Suitable for Boats, Caravans, Motorhomes and RVs (R3802DC)


Nova Kool R3802DC 12-24 Volt 100 Litre Marine Fridge Only Suitable for Boats, Caravans, Motorhomes and RVs (R3802DC)

Nova Kool R3802DC - 100 Litre Fridge Only

Single Door with Black Frame (Standard)

100 Litre Fridge with NO Freezer Compartment

Ask us for a quote - we can ship Australia wide!!

When the compressor is running, the R3802 draws only 2.1 amps @ 12 Volts DC - less than 0.5 amps on the 120VAC option. All Nova Kool Refrigerators and Freezers are equipped with a highly efficient variable speed Danfoss BD series compressor that is designed to run even while you are listed at a 30° angle. Average power use will vary depending on ambient temperature and how often the door is opened etc. but you can expect the R3802 to use less than 20 amp hours per day at 30C ambient temperature.

Volume:

  • 100 Liters Total Internal Volume
  • 100 litres of fridge space - No freezer box

Cut Out Dimensions:

  • 720 mm (H) X 515 mm (W) x 457 mm (D)
  • This model has a black flange included.

Features:

  • Highly efficient variable speed Danfoss BD Series compressor (fan included) that is designed to run well even at very high ambient temperatures and at angles up to 30° off level.
  • Supplied standard with Black door panels.
  • Door swing is right hand as standard but this can be changed prior to shipping or you can change this easily yourself.
  • Positive latch system
  • Storage for tall bottles
  • Reversible door swing
  • Replaceable door panels for a custom finish to your interior
  • Backed with Nova*Kool's Easy 2 Year Warranty Program on all components
  • Environmentally sound 134a refrigerant
  • CFC free urethane foam insulation in cabinet and doors
  • Magnetic door gaskets for positive seal
  • Stainless fasteners & hinges used throughout
  • Maintenance friendly & efficient static condenser
  • Low battery protection to help prevent full discharge of batteries
  • Strongest mounting flanges in the industry - Stainless Steel.
  • Made in Canada
  • All Nova Kool units can add the AC/DC Module as an optional extra if required
  • Compressor Fan - supplied
  • Interior Light - option

Options:

  • Standard with Right Hand Hinge Configuration. Left Hand Hinge available on request at no extra charge. The hinge side is user configurable, however, let us know your preference at the time of order and we can have the change made at factory prior to shipping/pick-up.



        Specifications

        Volume 100 Litres (3.5 cu.ft. ) volume
        100 Litres Internal Volume: All fridge version of the R3800 (no freezer box)

        Cut Out Dimensions 720mm Height
        425mm Width

        356mm Depth (measured from the back face of the mounting flange)

        Overall dimensions (Including flange)
        745mm Height
        515mm Width

        457mm Depth (including door and latch handle)
